Topdon TS004 Pro Thermal Imager Hunting Imaging Monocular

TOPDON TS004 Pro Thermal Imaging Monocular

The TOPDON TS004 Pro steps up to a 384 x 288 sensor and a 19 mm lens, detecting heat signatures out to 650 yards (594 m) even in complete darkness. TISR enhancement, wireless control through the TopInfrared app and an IP67 body make it a capable field tool.

Key Features

• 384 x 288 infrared resolution with TISR image enhancement and a 50 Hz frame rate
• 19 mm lens, with a detection range of 650 yards (594 m) and a recognition range of 146 yards (133 m)
• Digital zoom: 1x, 2x, 4x and 8x, plus a PIP mode that shows a 4x magnified view at screen centre alongside the wider scene
• Five colour palettes
• Screen brightness adjustable across 10 levels
• Built-in LED that doubles as a flashlight
• TopInfrared app: wireless control, remote operation, photo and video capture and over-the-air firmware updates
• 5,000 mAh battery for up to 10 hours of continuous use
• 32 GB internal storage, holding up to 270,000 thermal images or hours of video
• IP67 rated against rain and dust, operating from -10°C to 45°C
• Tripod compatible, with a hanging strap included

Specifications

• Resolution: 384 x 288
• Frame rate: 50 Hz
• Focal length: 19 mm
• Detection range: 650 yd (594 m)
• Recognition range: 146 yd (133 m)
• Magnification: 1x, 2x, 4x, 8x
• Battery: 5,000 mAh
• Protection: IP67
• Operating temperature: -10°C to 45°C
• Storage: 32 GB
• Net weight: 310 g
• Dimensions: 180 x 64 x 54 mm

What's in the Box

• TS004 Pro thermal imaging monocular
• USB-A to USB-C cable
• Hanging strap
• EVA carrying case
• User manual

A tripod is not included.
